• Digital display with 8.5'' LCD touchscreen• 2 Sylvac probe inputs (P2-P50)• 6 USB inputs for Sylvac instruments• Ethernet RJ45 connection• Manage up to 30 instruments simultaneously by software • Individual preset or by group
• Digital display with 8.5'' LCD touchscreen
• 2 Sylvac probe inputs (P2-P50)
• 6 USB inputs for Sylvac instruments
• Ethernet RJ45 connection
• Manage up to 30 instruments simultaneously by software
• Individual preset or by group
|
804.1300 |
|
|
Type |
D300S |
|
Max. Error [μm] |
P2: 1.5 / P5: 1.6 / P10: 1.6 / P25: 1.9 / P50: 3.9 |
|
Max. Error(1) [μm] |
P2: 0.5 / P5: 0.6 / P10: 0.6 / P25: 0.8 / P50: 1.5 |
|
Repeatability [μm] |
P2: 0.5 / P5: 0.6 / P10: 0.6 / P25: 0.8 / P50: 1.5 |
|
Frequency of measure [meas/sec] |
P2: 5 / P5: 5 / P10: 5 / P25: 5 / P50: 2.5 |
|
Overall dimensions [mm] |
330 x 175 x 77 |
|
Weight [kg] |
3.3 |
|
Case |
Steel / Plastic |
|
Protection rating according to IEC 60529 |
IP40 |
|
S_Connect |
RS232 / USB |
|
Programmable by PC |
Yes |
(1) Probe and unit calibrated
