NIDEC - CAG 2000

NIDEC - CAG 2000 is devised as a quick micrometer display which give you the high precision non-contact measuring instrument through air probe sensor. NIDEC - CAG-2000 with 1 or 2 channel air gauge, utilizes air flow and the resistance created between an object under test and the air gauge’s sensing probe. The air resistance (back pressure changes) with distance between the air probe and device under test. This air pressure change out of the air sensor can be scaled on by NIDEC - CAG-2000 to determine dimensional analysis as well as product quality tolerance.

NIDEC - CAG 2000 technology offers superb magnification and reliability to measure small tolerances down to 0.1 micron and even 0.01 micron with the 10 micron range. Due to its fast response, outstanding tolerance and accurate repeatability, NIDEC air gauge micrometers are the ideal investment to improve your quality measurements on the production floor of auto parts, aerospace and fast paced fastener fabrication.

NIDEC - CAG 2000 Features:

• Red/Orange/Green 3- color, 101 segment bar graph display with programmable set points makes it convenient to quickly view measurements and make go/no-go judgments
• Actual values presented on the 8-digit alphanumeric display
• The display can be programmed to show technical drawing tolerances
• In coordination with the max./min. masters and the air probe sensor, control keys are used to automatically calibrate the zero and full scale of the display
• Possesses a slim 2” (50mm) wide frame allowing for placement on any bench, plus enables a small foot-print when daisy-chaining units
• 10 types of setting can be programmed to save master values allowing quick retrieval for future tests
• Sensitivity adjustment knob allows fine tuning for more precise air control
• External signal input allows for automatic master calibration of zero and span with separate input switch
• Utilizing the standard serial output communications, data can be downloaded to a PC for processing and further evaluation
• Ranges down to 10 micron
• Several options are available such as judgment result output, rank output, BCD output, and Digimatic output
• If choosing a 2 channel sensor input, evaluation of three parameters consisting of 2 measurements along with their arithmetic result can be performed with a single column display

If you have any kind of questions or any interests for our product, feel free to contact us here
